Photo: Storm over Portage County, Ohio, June 24, 2017 - by James Guilford

Storm over Portage County, Ohio, June 24, 2017 – by James Guilford



Saturday night’s Open Night presented “interesting” situations. Shortly after arriving at the observatory, we saw rain arrive and heard thunder. Rain stopped, then started again as another compact thunderstorm passed over the village of Hiram. To the north we could see clear sky just outside the borders of the storm. To the south, over Garrettsville and Manuta, we could spy towering cumulus clouds and radar revealed intense rainfall. All of this weather around 8:30 to 9:00 and even a bit later. But at the appointed hour of 9:30, the sky began to clear overhead and we opened the dome.

There, in the southern shy, was Jupiter shining brightly. Hope? Nope! Storm delays and perhaps a bit of spring growth allowed Jupiter to slip behind the upper branches and leaves of a neighboring tree! Visitors arrived and we looked at mushy images of Jupiter pulled through little gaps between tree leaves. Surprisingly, occasional glimpses were had of the giant planet’s distinctive cloud bands and blurry dots of light — the Galilean Moons — could be seen. Then nothing, as Jupiter arced deeper into the branches. We fished around for a while, looking at a couple of bright stars through the murky atmosphere to the south. Saturn was lost in other trees and the messy air.

The faint, fuzzy Ring Nebula would be impossible, no? No. The sky to the east-northeast, inhabited by Lyra and the Ring, was crisp and clear. We rotated the dome, swung the big scope into position, and quickly found Messier 57 – the Ring Nebula. Of the night’s 19 visitors, those who were able to wait out the passage of clouds and darkening of sky were rewarded with clear, bright views of the famous planetary nebula; the beautiful end to a strange and frustrating evening.

Advertisements
Photo: The Ring Nebula (aka Messier 57). Credit: Walker County Observatory / Science@NASA - http://science.nasa.gov

The Ring Nebula (aka Messier 57). Credit: Walker County Observatory / Science@NASA – http://science.nasa.gov

Stephens Memorial Observatory of Hiram College will be open for public observing Saturday, June 24, from 9:30 to 11:00 PM. Featured that night will be Saturn, Jupiter, and the Ring Nebula. Other objects of interest may also be viewed.

The night’s observing depends upon clear skies and those have been in short supply this season! Cloudy skies at the starting time cancel the event and, in that case, the observatory will not open. No reservations are required and there is no admission fee for observatory public nights.

The Observatory is located on Wakefield Road (Rt. 82) less than a quarter of a mile west of Route 700 in Hiram. There is no parking at the Observatory. Visitors may park on permissible side streets near the Post Office, a short distance east of the observatory.

Photo: This image shows Jupiter's south pole, as seen by NASA's Juno spacecraft from an altitude of 32,000 miles (52,000 kilometers). Image credit: NASA/JPL-Caltech/SwRI/MSSS/Betsy Asher Hall/Gervasio Robles

This image shows Jupiter’s south pole, as seen by NASA’s Juno spacecraft from an altitude of 32,000 miles (52,000 kilometers). Image credit: NASA/JPL-Caltech/SwRI/MSSS/Betsy Asher Hall/Gervasio Robles



This image shows Jupiter’s south pole, as seen by NASA’s Juno spacecraft from an altitude of 32,000 miles (52,000 kilometers). The oval features are cyclones, up to 600 miles (1,000 kilometers) in diameter. Multiple images taken with the JunoCam instrument on three separate orbits were combined to show all areas in daylight, enhanced color, and stereographic projection.

JunoCam’s raw images are available at www.missionjuno.swri.edu/junocam for the public to peruse and process into image products.

NASA’s Jet Propulsion Laboratory manages the Juno mission for the principal investigator, Scott Bolton, of Southwest Research Institute in San Antonio. Juno is part of NASA’s New Frontiers Program, which is managed at NASA’s Marshall Space Flight Center in Huntsville, Alabama, for NASA’s Science Mission Directorate. Lockheed Martin Space Systems, Denver, built the spacecraft. Caltech in Pasadena, California, manages JPL for NASA.

More information about Juno is online at http://www.nasa.gov/juno and http://missionjuno.swri.edu

The scheduled May Open Night looked to be another “no-go” due to weather right up until about 90 minutes ahead of opening. Forecasts had, for days, called for overcast skies and inclement weather, and the day of the event bore that out. Then, defying forecasters and expectations, the sky began to clear. What looked to be another canceled Open Night turned into a decent time to look at Jupiter and the Hercules Star Cluster! With little advance publicity we hosted 10 observatory visitors, mostly local people but one couple drove all the way from Warren to participate.

Illustration: Jupiter and Moons

Simulated View: Jupiter and Galilean Moons as they appeared through our telescope Saturday Night, May 20, 2017. – SkySafari Pro

Though the sky was mostly-clear, seeing conditions were only fair to good. Through the grand Cooley Telescope at about 129X magnification, we were able to observe Jupiter and the planet’s distinctive north and south equatorial belts, the four Galilean Moons shining brightly in space nearby. As the night progressed we observed Jupiter’s Great Red Spot slowly rotate into view and even glimpsed its red color now and again! These were not the best views we have had of the “King of Planets,” but they were interesting, nonetheless.

The second object of the night was the Hercules Star Cluster (Messier 13) which, at first glance, looked like a cloudy smudge in the telescope’s wide-angle eyepiece. Now and again, however, with moments of good seeing and a little averted vision, we gained the impression of “graininess” as perhaps some of the globular cluster’s brighter stars stood out.

Photo: Baby bird inside observatory.

Saturday Night Alive: It happens every spring; baby birds of various ages get inside the observatory and most die. We captured this little one and put it in an area where we hope its parents find and care for it.



Illustration: Jupiter and His Moons as They will appear April 22, 2017, 10:00 PM EDT

Simulation: Jupiter and His Moons as They will appear April 22, 2017, 10:00 PM EDT


FINAL UPDATE: In all, 18 people and one dog took a chance on the changeable skies and paid the observatory a visit. Cloud cover ebbed and flowed, changing Jupiter’s appearance through the telescope. Interestingly, some of the better views of the planet actually occurred when thin clouds dimmed the brilliant planet cutting the glare. Viewers could make out the gas giant’s two major temperate cloud belts and sometimes one or two more! The four Galilean Moons were visible nearly all of the time. Owing to generally poor viewing conditions, the evening was limited to Jupiter only – dimmer objects were not available. The April 22 program will be repeated in May, given clear skies. By the way, before the dog came, a cat arrived with one of our visitors but refused to come inside, so kitty didn’t count!

UPDATE: Saturday, 9:00 PM: Opened when we could see Jupiter through thin clouds but expect the sky will cloud over again before clearing in the wee hours. Check out Twitter feed to the right for updates and closings…

UPDATE, Saturday, 4:00 PM: Forecasts call for partly- to mostly-cloudy conditions tonight. A final go/no-go decision on opening will be made later but, if we do open, we DO NOT expect to be able to see dimmer objects such as star clusters or the comet listed below. More later….

Stephens Memorial Observatory of Hiram College will be open for public observing Saturday, April 22, from 9:00 to 11:00 PM. This will be the first scheduled Open Night of the 2017 season. The “star” of the night will be planet Jupiter, brilliant in our southeast sky. We will also seek out the M3 star cluster and, later, the Hercules Cluster and (with some luck) Comet C/2015 V2. Other objects of interest may also be viewed. Of course, all of the night’s observing depends upon clear skies and those have been in short supply this spring!

Cloudy skies at the starting time cancel the event and, in that case, the observatory will not open. No reservations are required and there is no admission fee for observatory public nights.

The Observatory is located on Wakefield Road (Rt. 82) less than a quarter of a mile west of Route 700 in Hiram. There is no parking at the Observatory. Visitors may park on permissible side streets near the Post Office, a short distance east of the observatory.

Image: This illustration depicts NASA's Juno spacecraft at Jupiter, with its solar arrays and main antenna pointed toward the distant sun and Earth. Image Credit: NASA/JPL-Caltech

This illustration depicts NASA’s Juno spacecraft at Jupiter, with its solar arrays and main antenna pointed toward the distant sun and Earth. Image Credit: NASA/JPL-Caltech



NASA’s Juno mission, launched nearly five years ago, will soon reach its final destination: the most massive planet in our solar system, Jupiter. On the evening of July 4, at roughly 9 PM PDT (12 AM EDT, July 5), the spacecraft will complete a burn of its main engine, placing it in orbit around the king of planets.

During Juno’s orbit-insertion phase, or JOI, the spacecraft will perform a series of steps in preparation for a main engine burn that will guide it into orbit. At 9:16 PM EDT (July 4), Juno will begin to turn slowly away from the sun and toward its orbit-insertion attitude. Then 72 minutes later, it will make a faster turn into the orbit-insertion attitude.

At 10:41 PM EDT, Juno switches to its low-gain antenna. Fine-tune adjustments are then made to the spacecraft’s attitude. Twenty-two minutes before the main engine burn, at 10:56 PM, the spacecraft spins up from two to five revolutions per minute (RPM) to help stabilize it for the orbit insertion burn.

At 11:18 PM, Juno’s 35-minute main-engine burn will begin. This will slow it enough to be captured by the giant planet’s gravity. The burn will impart a mean change in velocity of 1,212 MPH (542 meters a second) on the spacecraft. It is performed in view of Earth, allowing its progress to be monitored by the mission teams at NASA’s Jet Propulsion Laboratory in Pasadena, California, and Lockheed Martin Space Systems in Denver, via signal reception by Deep Space Network (DSN) antennas in Goldstone, California, and Canberra, Australia.

After the main engine burn early July 5 (Eastern Daylight Time), Juno will be in orbit around Jupiter. The spacecraft will spin down from five to two RPM, turn back toward the sun, and ultimately transmit telemetry via its high-gain antenna. At Jupiter’s current distance of 536.9 million miles from Earth, radio signals will take about 48 minutes to reach the DSN.

Juno starts its tour of Jupiter in a 53.5-day orbit. The spacecraft saves fuel by executing a burn that places it in a capture orbit with a 53.5-day orbit instead of going directly for the 14-day orbit that will occur during the mission’s primary science collection period. The 14-day science orbit phase will begin after the final burn of the mission for Juno’s main engine on October 19.

JPL manages the Juno mission for NASA. The mission’s principal investigator is Scott Bolton of Southwest Research Institute in San Antonio. The mission is part of NASA’s New Frontiers Program, managed at the agency’s Marshall Space Flight Center in Huntsville, Alabama, for NASA’s Science Mission Directorate. Lockheed Martin Space Systems in Denver built the spacecraft.

Learn more about the June mission, and get an up-to-date schedule of events, at:

http://www.nasa.gov/juno

https://solarsystem.nasa.gov/planets/jupiter/junotoolkit


Mission Trailer Video: Secrets lie deep within Jupiter, shrouded in the solar system’s strongest magnetic field and most lethal radiation belts. On July 4, 2016, NASA’s Juno spacecraft will plunge into uncharted territory, entering orbit around the gas giant and passing closer than any spacecraft before. Juno will see Jupiter for what it really is, but first it must pass the trial of orbit insertion.

For much more on NASA’s Juno mission, click here!
